Table 2. General data - 375 to 550 ton units (continued)
Unit Size (tons)
375 380 440 450 500 550
Max. Water Temperature
°F 120 120 120 120 120 120
°C 48.9 48.9 48.9 48.9 48.9 48.9
Min. Water Pressure
psig
0 0 0 0 0 0
kPa 0 0 0 0 0 0
Max. Water Pressure
psig
150 150 150 150 150 150
kPa 1034.2 1034.2 1034.2 1034.2 1034.2 1034.2
1 Pass Arrangement
Evap Water Connection Size
(b)
in 8 8 8 8 8 8
mm 200 200 200 200 200 200
Minimum Flow
(c)
gpm
398 398 398 450 523 591
l/s 25.1 25.1 25.1 28.4 33.0 37.3
Maximum Flow
(c)
gpm
1750 1750 1750 1981 2303 2603
l/s 110.4 110.4 110.4 125.0 145.3 164.2
2 Pass Arrangement
Evap Water Connection Size
(b)
in 8 8 8 8 8 8
mm 200 200 200 200 200 200
Minimum Flow
(c)
gpm
198 198 198 224 260 294
l/s 12.5 L 12.5 14 16.4 18.5
Maximum Flow
(c)
gpm
871 871 871 986 1146 1295
l/s 55.0 55.0 55.0 62.2 72.3 81.7
Condenser
Length - Model Number Digit 25
(d)
F H F H H H
Quantity of Coil Modules
12 6 14 8 12 6 14 8 12 10 12 10
Quantity of Fans
# 12 6 14 8 12 6 14 8 12 10 12 10
Fan Diameter
in 37.5
mm 953
Coil Length
in 78.22
mm 1987
Coil Height
in 49.31
mm 1252
Fins/Ft 276
Ambient Temperature Range
Standard Ambient
°F (°C) 32 to 105 (0 to 40.6)
Low Ambient
°F (°C) 0 to 105 (-17.7 to 40.6)
Extreme Low Ambient
°F (°C) -20 to 105 (-28.9 to 40.6)
High Ambient °F (°C) 32 to 125 (0 to 52)
Wide Ambient
°F (°C) 0 to 125 (-17.7 to 52)
General Unit
Refrigerant
R-513A
Refrigerant Ckts
# 2
Minimum Load % 15 15 15 15 10 10
Refrigerant Charge/ckt
lb 366 177 405 215 366 177 405 215 348 309 348 309
kg
166 80 184 98 166 80 184 98 158 140 158 140
Oil OIL0076E
