General
Information
Table 2. Tube bundle locations for cooling only and free cooling units (inches)
Shell Cooling Only and Free Cooling Units
Size A B C D E F G H
032 2'-0-3/4" 2-5/8" 11-1/8" 7-1/4" 2'-7-3/4" 18" 10" 2'-2-3/8"
050 2'-6-3/4" 2-7/8" 9-3/8" 9-5/8" 3'-1-1/8" 1'-11-1/8" 1'-2-3/8" 2'-3-3/4"
080 3'-5-1/8" 4-1/4" 6-1/4" 11-3/8" 3'-7-3/4" 2'-4-1/8" 1'-7-1/4" 3'-7"
142 3'-10-3/8" 4-1/4" 6-5/8" 1'-2-5/8" 4'-2-3/8" 3'-3-1/8" 2'-0-7/8" 3'-8-3/8"
210 4'-5" 4-1 /2" 7-1 /8" 1'-5" 4'-11 " 3'-7-1 /2" 2'-4-1 /8" 3'-9-3/4"
250 5'-0-3/4" 5-1/2" 7-1/8" 1'-7-1/4" 5'-8-5/8" 3'-10-3/4" 2'-4-1/8" 4'-0-1/4"
Table 3. Tube locations for heat recovery and auxiliary condenser units (inches)
Shell Heat Recovery Auxiliary Condenser
Size J K L M J K L M
032 4'-6-3/8" 10-1/4" 1'-6-1/2" 4' 4'-6-3/4" 9-1/8" 1'-2" 3'-11-3/4
CVHE 050 5'-2-3/8" 1'-2-3/8" 1'-10-3/8" 4'-6" 5'-0-7/8" 9-1/8" 1'-2" 4'-8-1/4
CVHEF/G 050 6'-2-1/2" 1'-2-3/8" 1'-10-3/8" 4'-10" 6'-0-7/8" 9-1/8" 1'-2" 5'-0-5/8
080 T-3-1/8" 1'-7-1/4" 2'-4-7/8" 4'-8-3/8" 6'-10-1/2" 9-1/8" 1'-2" 5'-8-7/8
142 8'-7-3/8" 2'-0-7/8" 3'-2-1/2" 6'-2" 7'-9-3/8" 9-1/8" 1'-2" 7'-3-5/8
210 8'-7-1/2" 2'-4-1/8" 3'-7-1/2" 6'-6-5/8" 8'-7-5/8" 9-1/8" 1'-2" 3'-9-3/4
250 Not Available
Table 4. Typical shipping and operating weights (lbs.) (see note 1)
Cond Size Aux Cond Size 80 Aux Cond Size 130 Heat Rec Cond Free Cooling
CDSZ Ship Oper Ship Oper Ship Oper Ship Oper
032S 825 1057 960 1248 2119 2624 500 785
032L 825 1057 960 1248 2663 3263 500 785
050S 825 1057 960 1248 3170 4018 750 1290
050L 825 1057 960 1248 3985 4986 750 1290
080S 825 1057 960 1248 5340 6593 750 1360
080L 825 1057 960 1248 6683 8180 750 1360
142L 825 1057 960 1248 12180 14666 1400 2400
210L 825 1057 960 1248 16023 19299 1400 2400
Notes:
1. Unit-Mounted Starter Option = 530 Lbs. (Shipping and Operating)
2. Weights shown are accurate within ± 3% and are calculated with non-marine 150 psig water boxes. Marine-style water boxes may add considerably more weight;
contact LBU Marketing for details.
3. Operating weights include refrigerant, oil and water charges.
4. For more specific data on weights and isolator loading, refer to the unit submittal package.
IP Units

Trane CenTraVac Specifications

General

Compressor Type	Centrifugal
Dimensions	Varies by model
Frequency	50/60 Hz
Refrigerant	R-123 or R-134a
Operating Range	40°F to 65°F (Leaving Chilled Water Temperature)
