CVHE-SB-32A 48

The printer settings in the service settings menu must be set exactly the same on the printer

being used. This includes:

~ printer baud rate

~ printer parity

~ printer data bits

~ printer stop bits

~ printer handshaking

The above settings are usually configured on a printer by DIP switches. The dip switch settings

can be found in the manufacturers information provided with the printer.

Dip switch settings for the Okidata Microline 184 turbo printer follow:

Table 3

Switch Bank1

Duplex Control Module

(DCM)

Switch -1 -2 -3

SW1 ON OFF ON

Printer

Switch -1 -2 -3

SW1 OFF OFF ON

Parity Type

odd parity

even parity

Switch 1

off

Parity

No parity

With parity

Switch 2

off

Data Bits

8 bits

7 bits

Switch 3

off

Handshaking

Ready/Busy

X-on/X-off

Switch 4

off

Test Select

Circuit

Monitor

Switch 5

off

Mode Select

Print mode

Test mode

Switch 6

off
