ACC-SVN264B-EN 5
General Information - FIAECON102*
This section covers installation of low leak economizers for
6 to 12.5 ton downflow units in the B and C cabinet
(digit 39 = B,C).
Inspection
1. Unpack all components of the kit.
2. Check carefully for shipping damage. If any damage is
fo
und, report it immediately, and file a claim against the
transportation company.
3. Visually inspect the components for shipping damage as
soon
as possible after delivery, before it is stored.
Concealed damage must be reported within 15 days.
4. If concealed damage is discovered, stop unpacking the
shipm
ent.
5. Do not remove damaged material from the receiving
loca
tion. Take photos of the damage, if possible. The
owner must provide reasonable evidence that the damage
did not occur after delivery.
6. Notify the carrier’s terminal of damage immediately by
pho
ne and by mail. Request an immediate joint inspection
of the damage by the carrier and the consignee.
Note: Do not atte
mpt to repair any damaged parts until the
parts are inspected by the carrier’s representative.
Parts List
Table 1. Parts list
Qty Description
1 Low leak economizer
1 Mixed air sensor
1 Barometric relief mist filter
1 Top filler panel
(a)
(a) Model number digit 30 = D, E or F.
1 Top hood mist filter
1 Bag parts
1 Two piece hood
16 Self-drilling screws (33 Std. and 14 TEK)
2 Hood triangles
2 Smoke detector grommets
1 Hood base
26 Feet gasketing
1 Barometric relief hood
1 Powered exhaust gasket
1 Barometric relief triangle
1 Smoke detector bracket
1 FA hood front support
2 FA hood mist eliminator side retainer
1 FA hood mist eliminator rear block-off
