Periodic Maintenance
RTAA Log
Operator Settings:
Set Point Source Low Wtr Temp EXV Gain Comp [D/E]
Front Panel Chilled Wtr Setpt Condenser Limit Setpt
External Chilled Wtr Setpt [D/E] Phase Unbalance Protection [D/E]
Design Delta Temp Setpt Phase Reversal Protection [D/E]
Differential To Start Setpt Superheat Setpt
Chilled Water Pump [On/Auto] EXV Control Response Ckt 1
Chilled Water Pump Off Delay EXV Control Response Ckt 2
Front Panel Current Limit Setpt LVG Wtr Temp Cntrl Resp Setpt
External Current Limit Setpt [D/E] Fan Cntrl Deadband Bias, Ckt 1
Low Ambient Lockout [D/E] Fan Cntrl Deadband Bias, Ckt 2
Low Ambient Lockout Setpt Title Machine Config. Menu (+-+-+-)
Chilled Water Reset Type Compressor Model No. Prefix
Type, Reset Ratio Number of Compressors
Type, Start Reset Setpt Oil Loss Differential Setpt
Type, Max Reset Setpt Compressor A Tons
Ice Machine Control [D/E] Compressor B Tons
Panel Ice Termination Setpt Unit Model
Title Service Settings Fan Control [D/E]
Under/Over Voltage Protection [D/E] Variable Speed Fan, Circuit 1 [D/E]
Unit Line Voltage Variable Speed Fan, Circuit 2 [D/E]
Restart Inhibit Time Number of Fans, Circuit 1
Balanced CPRSR Starts & Hours [D/E] Number of Fans, Circuit 2
Display Units Reduced Inrush Starting [D/E]
Programmable Relay Setup Current Ovrld Setting, CPRSR A
External Circuit Lockout [D/E] Current Ovrld Setting, CPRSR B
Service Set-up Menu (++- - ++) Low Amb Unit, Half Airflow Fan [D/E]
Keypad/Display Lock Feature [D/E] Low Amb Unit, Two Speed Motor [D/E]
ICS Address Night Noise Setback [D/E]
LVG Wtr Temp Cutout Setpt Number of EXV Valves, Ckt 1
Low Rfgt Temp Cutout Setpt Number of EXV Valves, Ckt 2
