Trane TCCA User Manual

10 CHS-SVX02C-EN
RSAU0025F1 AHU
Model Number ......................................................... TCCB
Water Connection Size ............................. 2.5 in Victaulic
Ambient Operating Conditions
1
........................14–104°F
Supply Motor............................................................ 25 hp
Fused Disconnect.........................................................Yes
Number of Electrical Circuits ..........................................1
Discharge Configuration.................................. Horizontal
Flex Duct Connection Size ............................ 19 in round
Number of Discharge Air Connections ..........................2
Max Discharge Static Pressure ........................6.0 in ESP
Number of Return Air Connectors..................................3
Filter Rack (Qty and size)
2
... (4) 24 in x 24 in, (2) 24 in x 12 in
Nominal Air Flow (cfm) ..........................................10,000
Min/Max Air Flow (cfm)
3
..............................5,500/11,250
Selection is required for actual AHU performance.
1
For ambient conditions below 40°F, glycol is recommended.
2
Unit provided with standard 2 in filters. Filter rack will accept up to 95%
efficient MERV 14 filters.
3
Min/Max airflow is dependent upon external static pressure requirement.
Contact Rental Services for specific airflow and static pressure information.
Electrical Data
Voltage ........................................................ 460V 3-phase
Frequency ..................................................................60 Hz
Lug(s) can accept wire up to ..................... #3 AWG wire
Minimum Circuit Ampacity (MCA) ................... 44 amps
Maximum Overcurrent Protection (MOP)......... 70 amps
Provided with 50 ft of 4 conductor, 8 awg multicable
For additional electrical information, contac
t Trane Rental Services.
Performance Data
CFM 10,000
Air Pressure Drop through Unit (in H
2
0) 2.8
Cooling Coil
Entering Air DB/WB Temp (°F) 84/77
Leaving Air DB/WB Temp (°F) 55/54.9
GPM 155
Entering Water Temp (°F) 45
Leaving Water Temp (°F) 55
Coil Water Pressure Drop (ft H
2
0) 8.53
Sensible Capacity (MBH) 323.9
Total Capacity (MBH) 778.8
Coil Face Area (sq ft) 19.9
Coil Rows 8
Heating Coil
Entering Air DB/WB Temp (°F) 45
Leaving Air DB/WB Temp (°F) 78
GPM 36
Entering Water Temp (°F) 180
Leaving Water Temp (°F) 160
Coil Water Pressure Drop (ft H
2
0) 2.38
Total Capacity (MBH) 357.89
Coil Face Area (sq ft) 19.9
Coil Rows 1
Water Flow Rates
Minimum Maximum
CW Coil Flow (GPM) 70 200
CW Coil Pressure Drop (ft H
2
0) 2.14 13.66
HW Coil Flow (GPM) 10 125
HW Coil Pressure Drop (ft H
2
0) 0.2 28.07
Dimensions and Weights
Length 19 ft 0 in
Width 6 ft 11 in
Height 7 ft 6 in
Weight 8,350 lb
Width includes permanently mounted piping manifold.
Lifting Device: Fork Lift or Crane
