CHS-SVX02C-EN 7
RSAU0025F0 AHU
Model Number ......................................................... TCCA
Water Connection Size ............................. 2.5 in Victaulic
Ambient Operating Conditions
1
........................14–104°F
Supply Motor............................................................ 20 hp
Fused Disconnect.........................................................Yes
Number of Electrical Circuits ..........................................1
Discharge Configuration.................................. Horizontal
Flex Duct Connection Size ............................ 19 in round
Number of Discharge Air Connections ..........................2
Max Discharge Static Pressure ......................5.82 in ESP
Filter Rack (Qty and size)
2
... (4) 24 in x 24 in, (2) 24 in x 12 in
Nominal Air Flow (cfm) ..........................................10,000
Min/Max Air Flow (cfm)
3
..............................5,500/11,250
Selection is required for actual AHU performance.
1
For ambient conditions below 40°F, glycol is recommended.
2
Unit provided with standard 2 in filters. Filter rack will accept up to 95%
efficient MERV 14 filters.
3
Min/Max airflow is dependent upon external static pressure requirement.
Contact Rental Services for specific airflow and static pressure information.
Electrical Data
Voltage ........................................................ 460V 3-phase
Frequency ..................................................................60 Hz
Lug(s) can accept wire up to ..................... #3 AWG wire
Minimum Circuit Ampacity (MCA) ................ 42.5 amps
Maximum Overcurrent Protection (MOP)......... 60 amps
Provided with 50 ft of 4 conductor, 8 awg multicable
For additional electrical information, contac
t Trane Rental Services.
Performance Data
CFM 10,000
Air Pressure Drop through Unit (in H
2
0) 2.98
Entering Air DB/WB Temp (°F) 84/77
Leaving Air DB/WB Temp (°F) 50/49.9
GPM 150
Entering Water Temp (°F) 44
Leaving Water Temp (°F) 56
Coil Water Pressure Drop (ft H
2
0) 4.55
Sensible Capacity (MBH) 379.73
Total Capacity (MBH) 909.85
Coil Face Area (sq ft) 20.43
Coil Rows 10
Water Flow Rates
Minimum Maximum
Flow (GPM) 70 340
Pressure Drop (ft H
2
0) 1.38 19.57
Maximum water side pressure is 150 psi (2.31’ H
2
0 = 1 psi)
Dimensions and Weights
Length 16 ft 1 in
Width 7 ft 4 in
Height 7 ft 6 in
Weight 6,000 lb
Width includes permanently mounted piping manifold.
Lifting Device: Fork Lift or Crane
