Rigging Guidelines
40 CHS-SVX02C-EN
Rigging Guidelines
Each AHU has forklift pockets and either an overhead
lifting frame or base mounted lifting lugs (Figure 36). Refer
to pages7-30 for unit dimensions and weights.
WARNING
Heavy Objects!
Use a forklift/crane of suitable capacity to move the
unit. Failure to properly lift unit could result in death or
serious injury or possible equipment or property-only
damage.
Figure 36. 10,000 cfm Unit in Frame
To Next Page
