Dimensions and Weights
14 UNT-SVX07J-EN
Component Data
Table 1. Fan coil and cabinet heater component data
Unit Size 02 03 04 06 08 10 12
Coil Data
Face Area (ft
2
) 0.80 0.80 1.10 1.60 2.10 3.20 3.20
L x D x H (in.)
2-Row 15 x 1.7 x 8 15 x 1.7 x 8 20 x 1.7 x 8 29.5 x 1.7 x 8 38 x 1.7 x 8 57 x 1.7 x 8 57 x 1.7 x 8
3-Row 15 x 2.6 x 8 15 x 2.6 x 8 20 x 2.6 x 8 29.5 x 2.6 x 8 38 x 2.6 x 8 57 x 2.6 x 8 57 x 2.6 x 8
4-Row 15 x 3.5 x 8 15 x 3.5 x 8 20 x 3.5 x 8 29.5 x 3.5 x 8 38 x 3.5 x 8 57 x 3.5 x 8 57 x 3.5 x 8
Volume (gal.)
1-Row (Heat) 0.06 0.06 0.08 0.11 0.14 0.21 0.21
2-Row 0.120.120.150.220.280.420.42
3-Row 0.18 0.18 0.23 0.33 0.42 0.62 0.62
4-Row 0.240.240.300.440.560.830.83
Refrigerant volume (cubic in.)
3-Row ---- ---- ---- 76.23 97.02 143.22 ----
4-Row ---- ---- ---- ---- ---- ---- 191.73
Fins per inch
2-Row 12121212121212
3-Row 12 12 12 12 12 12 12
3/1-Row high capacity 16 16 16 16 16 16 16
4-Row 12121212121212
Reheat Coil Data (1-Row), Standard, or High-Capacity
1
Hot Water or Steam
Face Area (ft
2
) 0.60 0.60 0.80 1.20 1.60 2.40 2.40
L x D x H (in.) 15 x 1.5 x 6 15 x 1.5 x 6 20 x 1.5 x 6 29.5 x 1.5 x 6 38 x 1.5 x 6 57 x 1.5 x 6 57 x 1.5 x 6
Volume (gal.) 0.12 0.12 0.15 0.22 0.28 0.42 0.42
Standard Capacity
(a)
Fins/
in.
4444444
High-Capacity Fins/in. 12 12 12 12 12 12 12
Fan/Motor Data
Fan Quantity 1 1 1 2 2 3 3
Size — Dia x Width (in.) 6.31 x 4 6.31 x 6.5 6.31 x 7.5 6.31 x 6.5 6.31 x 7.5 (1) 6.31 x 7.5 6.31 x 7.5
Size — Dia x Width (in.) (2) 6.31 x 6.5
Motor Quantity 1111122
Filter Data
1-in. Throwaway and Pleated Media
Quantity 1 1 1 1 1 1 1
Size (in.) 8-7/8 x 19-1/8 8-7/8 x 19-1/8 8-7/8 x 24-1/8 8-7/8 x 33-5/8 8-7/8 x 42-1/8 8-7/8 x 61-1/8 8-7/8 x 61-1/8
1-in. Fresh Air Filter (only on cabinet styles D, E, and H with bottom return and fresh air opening)
Quantity 1111111
Size (in.) 5-1/2 x 19-1/8 5-1/2 x 19-1/8 5-1/2 x 24-1/8 5-1/2 x 33-5/8 5-/2 x 42-1/8 5-1/2 x 61-1/8 5-1/2 x 61-1/8
(a) Standard and high-capacity reheat coils share the same component data except that standard capacity reheat coils have 4 fins/in. while high-capacity
reheat coils have 12 fins/in
Table 2. Low vertical fan coil component data
Unit Size 03 04 06
Coil Data
Face Area (ft
2
) 1.10 1.60 2.10
L x D x H (in.)
2-Row 20 x 1.7 x 8 29.5 x 1.7 x 8 38 x 1.7 x 8
3-Row 20 x 2.6 x 8 29.5 x 2.6 x 8 38 x 2.6 x 8
Volume (gal.)
1-Row (Heat) 0.08 0.11 0.14
2-Row 0.15 0.22 0.28
3-Row 0.230.330.42
Fins per inch
2-Row 121212
3-Row 12 12 12
Fan/Motor Data
Fan Quantity 1 1 1
Size — Dia x Width (in.) 5.00 x 23.00 5.00 x 32.00 5.00x 41.00
Motor Quantity 1 1 1
Filter Data
1-in. Throwaway
Quantity 111
Size — in. 8-7/8 x 24-1/8 8-7/8 x 33-5/8 8-7/8 x 42-1/8
Note: Low vertical model not available for Force Flo cabinet heaters.
