BAS-SVX04C-EN • Wireless Sensors 7
General Information
This section provides a description of the sensors, as well as part numbers and
dimensions.
Product Description
Trane
®
wireless sensor sets are compatible with any Trane unit controller that uses a
standard 10 kΩ temperature input. The sets include sensor, receiver, wiring harness, and
two AA lithium batteries. No further software or hardware is necessary for site
evaluation, installation, or maintenance. Zone temperature is standard on all models.
Notes:
• The information in this manual applies to both factory and field installed versions of
the Trane wireless sensor sets.
• A service tool cannot be connected to a Trane wireless sensor.
Trane wireless sensors include the following models:
Model WDS
This configurable sensor has an LCD display. It provides the same functions as many
currently available Trane wired sensors. Configurable features include:
– Temperature units: Fahrenheit (ºF) or Celsius (ºC)
– Temperature resolution: 1.0, 0.5, or 0.1 degrees
– Ability to display setpoint only (zone temperature does not display)
– Single, dual, or no setpoint
– System settings: auto, off, cool, heat, emergency heat
– Dead band (heat/cool setpoint offset for dual setpoint systems)
– Fan settings: high, medium, low, auto, off
– Timed override request function
– Lockable settings to protect agains unauthorized use
– Service pin request
Model WTS
This sensor measures and transmits the zone temperature only.
Model WZS
This sensor set transmits the zone temperature, all zone temperature setpoint functions,
temporary occupancy (timed override), and unoccupied (cancel) information to the
receiver. The receiver electrically reproduces the zone temperature resistance, all zone
temperature setpoint function resistances, and temporary occupancy/unoccupied
information as sent by the sensor.
