SAFETY HARNESS
13
SAFETY HARNESS (optional)
Provision is made for the use of three-point attachment safety belts;
anchorage points are built into the vehicle and are
shown on Figs. 12 and 13.
Fitting the Harness
Remove the shoulder strap anchor bolt, crimped washer and
collar from each wheelarch, pass the bolt through the strap
attachment, fit the crimped washer and collar, as shown on Fig. 11,
and refit to the vehicle.
By means of the latched hooks fit the lap strap to the eye bolts, Fig.
13. The shoulder strap will have a half twist when fitted to the
wheelarch, this is the correct position.
Using the Harness
Pass the buckle end of the belt around the hips, and fasten the
belt by pushing the locking plate into positive engagement with the
buckle. This is denoted by a "click". To release the harness depress
the centre panel.
