General Information
61
Throttle Control
1. Throttle open position
2. Throttle closed position
All models have an electronic throttle
twist grip to open and close the
throttles via the engine control unit.
There are no direct-acting cables in the
system.
The throttle grip has a resistive feel to
it as it is rolled rearwards to open the
throttles. When the grip is released it
will return to the throttle closed position
by its internal return spring and the
throttles will close.
There are no user adjustments for the
throttle control.
If there is a malfunction with the throttle
control the Malfunction Indicator Light
(MIL) becomes illuminated and one of the
following engine conditions may occur:
• MIL illuminated, restricted engine
RPM and throttle movement
• MIL illuminated, limp-home mode
with the engine at a fast idle
condition only
• MIL illuminated, engine will not start.
For all of the conditions mentioned
contact an authorized Triumph dealer
as soon as possible to have the fault
checked and rectified.
Clutch Lever Adjusters
Warning
Do not attempt to adjust the levers
with the motorcycle in motion as this
may lead to loss of motorcycle control
and an accident.
After adjusting the levers, operate the
motorcycle in an area free from traffic
to gain familiarity with the new lever
setting.
Do not loan your motorcycle to anyone
as they may change the lever setting
from the one you are familiar with
causing loss of motorcycle control and
an accident.
An adjuster is mounted to the front
clutch lever. The adjuster allows the
distance from the handlebar to the
clutch lever to be changed to suit the
span of the rider's hands.
Speed Twin Only
2
1
1. Clutch lever
2. Adjusting screw
