General Information
73
Street Scrambler Seat Removal
Note
If a passenger seat is equipped, it must
be removed before removing the rider’s
seat.
If a luggage rack is equipped, the rider’s
seat can be removed without removing
the luggage rack.
Passenger Seat Removal
cjyn
2
1
1. Passenger seat
2. Fastener
To remove the passenger seat:
• Remove the fastener securing the
passenger seat to the luggage rack
subframe.
• Lift the seat up from the back and
slide rearwards to remove it from
the motorcycle.
Rider’s Seat Removal
To remove the rider’s seat:
• Remove the passenger seat
if equipped.
• Insert the ignition key into the seat
lock and turn it counterclockwise
while pressing down on the rear of
the seat. This will release the seat
from its lock.
• Lift the seat up from the back and
slide rearwards to remove it from
the motorcycle.
Street Scrambler Seat Installation
Warning
To prevent detachment of a seat
during riding, after installation
always grasp the seat and pull firmly
upwards. If the seat is not correctly
secured it will detach from the lock.
If the seat is not correctly secured it
will detach from the lock.
A loose or detached seat could cause
loss of motorcycle control and an
accident.
Rider’s Seat Installation
To install the rider’s seat:
• Engage the seat’s tongue under the
fuel tank.
• Press firmly down in the center of
the seat to engage the lock.
Note
An audible click can be heard when the
seat is correctly engaged in the lock.
• Grasp the seat and make sure it is
securely retained.
Passenger Seat Installation
To install the passenger seat:
• Make sure that the rider’s seat is
correctly installed.
• Align the front locating lugs on the
passenger seat to their locating
slots on the luggage rack subframe.
