TTP-243 Plus/ 243E Plus/
342 Plus Bar Code Printer
2. SUPPLY SPECIFICATIONS
2.1 Types of Paper
Two types of media are available for TTP-243: label and ticket.
In TTP-243, there are two types of sensors for paper: gap sensor and black mark
sensor.
Label and ticket can be further classified into direct thermal type or thermal transfer
type.
2.2 Specifications
Items
Label
Paper Width
Max.114mm
Min. 25mm
Length (Pitch)
12～2286mm
Paper
Thickness
0.20 mm
Paper Weight
Max 240 g/m
2
Max. Roll
Diameter
(1” core)
Inner roll diameter. Max 4.3” (110mm)
External roll diameter. Max 8.4”
(214mm)
Roll Up Method
Print surface wound outside as
standard
Paper Core ID.
25.7±0.3mm
Note:
(1). The width and thickness quoted above are said of the label plus its backing paper.
(2). Likewise, the approval of label entails that of its backing paper.
(3). In the peel off mode, the minimum pitch is 35mm.
(4). In the cutter mode, it is required the paper be wound outside. Otherwise, paper jam
tends to result.
(5). In the cutter mode, the paper thickness is 0.2 mm at maximum, and the paper weight is
100 g/m
2
at maximum.
(6). Paper shape is as shown on next page.
(7) Tag is 0.2mm in thickness, and is less than 100g/m
2
in weight.
