TSI Instruments FHC50 User Manual

Appendix A
72
Velocity Sensor
Range ........................................
0 to 1,000 ft/min (0 to 5.08 m/s)
Resolution ..................................
1 ft/min (0.00508 m/s)
Temperature Compensation
Range ........................................
55 to 95°F
Power Dissipation ......................
0.09 watts at 0 ft/min. (0 m/s)
0.14 watts at 100 ft/min. (0.508 m/s)
Dimensions (D x H) ...................
2.75 in.  1.25 in. (70 mm  32 mm)
Weight ........................................
0.2 lb (0.1 kg)
Sensor Cable Specifications .....
4-conductor, 22 AWG, 4-pin polarized at both ends with a
standard length of 6 ft (a maximum length of 10 ft).
Vertical Sash Sensor
Cable Type ................................
Nylon-coated stainless steel
Maximum Retraction ..................
50 in. (1,270 mm)
Resistance .................................
0 to 10,000 
Electrical Cable ..........................
2-conductor, 24 AWG
12 ft (3.6 m)
Dimensions ................................
2.0 in  3.5 in  3.1 in (51 mm  88 mm  79 mm)
Damper/Actuator
Types of Actuator ......................
Electric
Input Power ................................
Electric: 24 VAC, 50 VA max
Time for 90° Rotation .................
1.5 sec.
*Specifications are subject to change without notice.
