Internet Alarm Communicator Installation Manual
Communications Reporting Codes
[023] Panel Absent Trouble
Default (FF)
Program 00 to disable this event or FF to enable. This event will occur when communications with
the panel have been lost for more than 60 seconds.
[024] Panel Absent Trouble Restore
Default (FF)
Program 00 to disable this event or FF to enable. This event will occur when communications with
the control panel have resumed.
System Test Options
Test Transmissions to Primary Receiver, with Backup to Secondary Receiver:
Set Ethernet section [026] to (FF); [027] to (00).
• If the test transmission fails to the primary receiver it will backup to the secondary receiver.
• If the test transmission fails to the secondary receiver an FTC trouble will be generated.
Independent Test Transmission to Primary and Secondary Receivers:
Set Ethernet section [026] to (FF); [027] to (FF).
• The module will send periodic test transmissions to each receiver independently, with no back-
ups.
• If the test transmission fails to any of the programmed receivers, an FTC trouble will be gener-
ated.
Alternating Test Transmission:
Alternate test transmission can be enabled or disabled in section [005] toggle option [7].
Alternating Test Transmission with backup receivers:
Set Ethernet section [026] to (FF); [027] to (00).
Interval 1:
• If the test transmission fails to the primary receiver it will backup to the secondary receiver.
• If the test transmission fails to the secondary receiver an FTC trouble will be generated.
Interval 2:
• If the test transmission fails to the secondary receiver it will backup to the primary receiver.
• If the test transmission fails to the primary receiver an FTC trouble will be generated.
Test Transmission Unique to Primary and Secondary Receivers:
Set Ethernet section [026] to (FF); [027] to (FF).
Interval 1:
• The module will send periodic test transmissions to primary receivers (Ethernet primary) inde-
pendently, with no backups.
• If the test transmission fails to any of the programmed primary receivers, an FTC trouble will
be generated.
Table 9: Communications Reporting Codes
Event
SIA
Identifier
SIA
Reporting
Code
CID
Qualifier
CID
Event
Code
CID
Reporting
Code
CID
User/
Zone
[023] Panel Absent Trouble ET 0001 1 3 55 001
[024] Panel Absent Trouble Restore ER 0001 3 3 55 001
[026] Ethernet 1 Test Transmission RP 0001 1 6 A3 951
[027] Ethernet 2 Test Transmission RP 0002 1 6 A3 952
[030] FTC Restore YK 0001 3 3 54 001
