7
Internet Alarm Communicator Installation Manual
Ratings and Compatibility
NOTE: Enter [*][8][Installer Code][900] at keypad to view the panel version number.
Products or components of products, which perform communications functions only, shall comply
with the requirements applicable to communications equipment as specified in UL60950 or CAN
CSA C22.2. No. 60950-1, Information Technology Equipment - Safety - Part 1: General Require-
ments. Where network interfaces are external to the control unit or receiver, compliance to CAN
CSA C22.2. No. 60950-1 is adequate. Such components include, but are not limited to: hubs, rout-
ers, NIDs, third-party communications service providers, DSL modems, and cable modems.
Encryption
The communicator uses 128-Bit AES encryption. Encryption can only be enabled from the moni-
toring station receiver. Each receiver (Ethernet 1 and 2) can independently have encryption
enabled or disabled. When encryption is enabled, the central station will configure the device to
encrypt communications the next time the communicator module performs a communication to
that receiver.
NOTE: Packets will start being encrypted only after the next event is sent to that receiver, or if the
unit is restarted.
NOTE: Before leaving the installation site, the communicator TL280(R) Ethernet line shall be
connected via an APPROVED (acceptable to the local authorities) Network Interface
Device (NID) (e.g., for UL Installations, UL60950 listed NID). All wiring shall be per-
formed according to the local electrical codes.
The communicator shall be installed by service persons only (service person is defined as a person
having the appropriate technical training and experience necessary to be aware of hazards to which
that person may be exposed to in performing a task and can also take measures to minimize the
risks to that person or other persons). The Communicator shall be installed and used within an
environment that provides the pollution degree max 2, overvoltages category II, in non-hazardous,
Table 1: Communicator Ratings
Model TL280(R)
Power Supply Ratings
Input Voltage
10.8-12.5 VDC
Power is supplied from the panel’s PC-Link header or a PCL-422 module in
remote cabinet installations. In remote cabinet installations, the PCL-422
module located with the communicator is powered by either an HSM2204
or an HSM2300. Refer to the PCL-422 installation instructions for details.
Current Consumption
Current 100mA @ 13.66V
Environmental Specifications
Operating Temperature 14°F to 131°F (-10°C to 55°C)
Humidity 5% ~ 93% relative humidity, non-condensing
Mechanical Specifications
Board Dimensions (mm) 100 × 150 × 15
Weight (grams) with bracket 290
Table 2: Compatible Receivers and Panels
Communicator
Receiver/
Panel
Description
TL280(R)
Receiver
• Sur-Gard System I Receiver, version 1.13+
• Sur-Gard System II Receiver, version 2.10+
• Sur-Gard SG-DRL3-IP, version 2.30+ (for Sur-Gard System III Receiver)
• Sur-Gard SG-DRL4-IP version 1.20+ (for Sur-Gard System IV Receiver)
•
Sur-Gard SG-DRL5-IP version 1.00+ (for Sur-Gard System 5 Receiver)
Panel
• HS2016
• HS2032
• HS2064
• HS2128
PRE INSTALLATION CONFIGURATION
COMMUNICATOR INSTALLATION CONFIGURATION
