Internet Alarm Communicator Installation Manual
System Options
[001] Ethernet IP Address
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[002] Ethernet IP Subnet Mask
Default (255.255.255.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[003] Ethernet Gateway IP Address
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[004] Receiver Supervision Interval
Default (0087/135) Valid range: 0000 - FFFF.
|____|____|____|____|
[005] System Toggle Options
|____| [1] Ethernet Receiver 1 Supervised Default (OFF).
|____| [2] Reserved.
|____| [3] Supervision Type Default (OFF).
|____| [4] Reserved.
|____| [5] Reserved.
|____| [6] Remote Firmware Upgrade Default (ON).
|____| [7] Alternate Test Transmission Default (OFF).
|____| [8] Reserved.
[006] System Toggle Options 2
|____| [1] Ethernet Receiver 1 Enabled Default (ON).
|____| [2] Ethernet Receiver 2 Enabled Default (ON).
[007] DNS Server IP 1
Programming not permitted on UL/ULC listed sys-
tem.
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[008] DNS Server IP 2
Programming not permitted on UL/ULC listed sys-
tem.
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
Programming Options
[010] System Toggle Options 3
|____| [1] Reserved.
|____| [2] Visual Verification Default (OFF).
|____| [3] Reserved.
[011] Installer Code
Default (CAFE) Valid range: 0000 - FFFF.
|____|____|____|____|
[012] DLS Incoming Port
Default (0BF6/3062) Valid range: 0000 - FFFF.
|____|____|____|____|
[013] DLS Outgoing Port
Default (0BFA/3066) Valid range: 0000 - FFFF.
|____|____|____|____|
[015] DLS Call-Up IP
Default (000.000.000.000)
|____|____|____||____|____|____||____|____|____||____|____|____|
[016] DLS Call-Up Port
Default (0000) Valid range: 0000 - FFFF.
|____|____|____|____|
[020] Time Zone
Default (00) Valid range: 00 - 99.
|____|____|____|____|
[021] Account Code
Default (FFFFFF) Valid range: 000001 - FFFFFE.
|____|____|____|____|____|____|
[022] Communications Format
Default (04) Program 03 (CID), 04 (SIA).
|____|____|
[023] Panel Absent Trouble
Default (FF); Program 00 disable or FF enable.
|____|____|
[024] Panel Absent Trouble Restore
Default (FF) Program 00 disable or FF enable.
|____|____|
System Test Options
[026] Ethernet 1 Transmission
Default (FF) Program 00 disable or FF enable.
|____|____|
[027] Ethernet 2 Transmission
Default (00) Program 00 disable or FF enable.
|____|____|
[030] FTC Restore
Default (FF) Program 00 disable or FF enable.
|____|____|
[037] System Firmware Update Fail
Default (FF) Program 00 disable or FF enable.
|____|____|
[034] Communicator Firmware Update
Successful
Default (FF) Program 00 disable or FF enable.
|____|____|
ETHERNET PROGRAMMING WORKSHEETS
