27
Internet Alarm Communicator Installation Manual
[115] Ethernet Receiver 2 UDP Local Port
Default (0BF9/3065)
Use this section to program the value of the local outgoing port. You can set the value of this port
when your installation is located behind a firewall and must be assigned a particular port number
as determined by your network administrator. Valid range: 0000 - FFFF.
NOTE: Do not program Ethernet receiver 1 and Ethernet receiver 2 port with the same value.
[116] Ethernet Receiver 2 Domain Name
Default ( )
Programming this section is not permitted on a UL/ULC listed system.
Enter the Domain Name as 32 character ASCII.
Ethernet Options
[124] Ethernet Test Transmission Time
Default (9999)
Enter a 4 digit number (0000-2359) using the 24-hour clock format (HHMM) to set the test trans-
mission time of day. Valid range: 00 - 23 hours (HH) and 00 - 59 minutes (MM). Programming a
value of 9999 will disable the test transmission time.
NOTE: The internal date and time will automatically be programmed when the unit communi-
cates with the primary receiver.
[125] Ethernet Test Transmission Cycle
Default (000000)
This value represents the interval between test transmissions, in minutes. Valid range: 000000 -
999999 minutes. Once the unit has sent the initial periodic test transmission, all future test trans-
missions will be offset by the programmed number of minutes. See sections [026] - [029].
NOTE: Minimum value is 000005 minutes. Programming an interval that is less than 5 minutes
will disable test transmission.
Receiver Diagnostic Testing
[901] Diagnostic Test Transmission
[1]Ethernet 1 (OFF).
[2] Ethernet 2 (OFF).
[3] - [8] Reserved (OFF).
This section may be used by the installer to force the communicator to send an immediate test
transmission to specific receivers, to verify that the communications paths are available.
Diagnostic test transmission failure will indicate as FTC trouble (yellow LED = 9 flashes).
If an FTC error occurs when testing all receivers, select only one receiver and repeat test to
isolate the receiver that is not communicating.
NOTE: Sending a test transmission to a receiver that is not programmed generates FTC trouble.
System Information (Read Only)
NOTE: Sections [983] - [998] are provided for information (read only). Values in these sections
cannot be modified by the installer.
[983] Firmware Update Diagnostics Section
Firmware updates for panel and the communicator itself can be made from the communicator.
Table 11: Ethernet Test Transmission Interval
Test Transmission Interval Daily Weekly Monthly
Programmed Minutes 001440 010080 043200
