▶If you input the user name by clicking [Search
name] button, the registered user list including
the characters is shown.
If you click [BACK] button in this window, you
can move to the „3.3. User management‟ menu.
Ex) If you searched with ‚ma‛, all the users
who contain ‚ma‛ in their name are
searched.
3.4. Network setting
If you select [Network] in the main menu, the following window appears.
▶Basic setting : Same with the window at the left
side.
Select the method [Static IP] if the static IP is
allocated from the connected network, and select
[DHCP] if the IP is allocated from the DHCP server
in the connected network.
If you selected [Static IP], set the IP address,
subnet mask, and gateway. And if you selected
[DHCP], you don‟t have to set them.
DNS entry is possible instead of IP in the [Server
IP], and if you use specific DNS server, input the IP
address of [DNS] server together. Check DN□
when typing DNS in order to type in English.
▶[Port]: The basic port value of the authorization server (UNIS server) is „9870‟, and if
you change the value, you should change the server program with the same value, so
be cautious.
▶[Terminal ID]: It is unique ID used by the terminal to distinguish the terminals and the
default value is „1‟. It should be the same with the ID of the terminal registered, and
