Unitech HT682 User Manual

Docking Station
USB Cradle
For data transmission, plug one end of your
HT682's USB communication cable into your
PC's USB Port and the other end into the
HT682 Docking Station's USB port. To
simultaneously charge the HT682, plug the AC
power adaptor into the power receptacle on
the Docking Station.
RF Communication
Windows CE can support TCP/IP protocol and
the user can link to the Internet via the
settings under “ Network and Dial-up
Connections”.
In the Network and Dial-up Connections, go to
PRISM1 to set up the IP to connect to internet.
Using ActiveSync
Using Microsoft ActiveSync, you can synchronize and transfer information between your
desktop computer and PDA Scanner. The most current version of ActiveSync can be
downloaded from www.microsoft.com.
Additional Capabilities
With ActiveSync, you can also:
 Back up and restore your device data.
 Copy (rather than synchronize) files between your device and desktop computer.
 Control when synchronization occurs by selecting a synchronization mode. For example,
you can synchronize continually while connected to your desktop computer or only when
you choose the synchronize command.
 Select which information types are synchronized and control how much data is
synchronized. For example, you can choose how many weeks of past appointments you
want synchronized.
24

Unitech HT682 Specifications

General

Certification	CE, FCC, BSMI, VCCI, CCC, SRRC, RoHS
Product color	Black
LED indicators	Yes
Phone function	-
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI, PLANET, POSTNET, U.P.C.
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Codablock, Code 49, Composite Codes, Data Matrix, MaxiCode, MicroPDF417, PDF417, QR Code
Display diagonal	2.8 \
Display resolution	- pixels
Speakers	Mono
ROM capacity	512 MB
Internal memory	0.512 GB
Internal memory type	SDRAM
Compatible memory cards	SDHC
Maximum memory card size	32 GB
Processor family	OMAP AM3703
Processor frequency	0.8 GHz
USB 2.0 ports quantity	1
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery capacity	- mAh
Data network	EDGE, GPRS, GSM, HSDPA, UMTS
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1900, 2100 MHz
Security algorithms	AES, EAP-FAST, EAP-TLS, EAP-TTLS, PEAP, WEP, WPA, WPA2
Operating system installed	Windows Embedded Compact Professional 6.0 R3

Weight and Dimensions

Depth	30 mm
Width	55 mm
Height	170 mm
Weight	- g
