MS100 Manual
Bar Code Symbologies, continued
Standard 2 of 5 / Toshiba Code (China Postal Code)
Maximum Length defines the maximum length the user will
accept for a valid bar code. Default is “48”.
•
Minimum Length defines the minimum length the user will
accept for a valid bar code. Default is “4”.
•
Check Digit defines whether or not a check digit (to insure data
accuracy) is calculated, and if so, whether it should be sent or
not. Default is “Not Calculate”.
•
Fix Length (by first 3 reads) fixes the length of acceptable
subsequent bar code reads from the first three bar codes read.
Useful as a data verification if all bar codes are of a consistent
length. Default is “No”.
•
Toshiba Code ID is the same as S25 Code ID (above), but
instead applicable to Toshiba Code. Default is letter “C”.
•
S25 Code ID is a user-definable identification letter for S 2 of 5,
which is referred to in the “Use Code ID” function (see page 11).
Default is letter “H”.
•
Enabled toggles the ability for the keyboard/scanner to read S 2
of 5 / Toshiba Code on or off. Default is “No”.
•
Interleaved 2 of 5
Enabled toggles the ability for the keyboard/scanner to read I 2
of 5 on or off. Default is “Yes”.
•
Code ID is a user-definable identification letter for I 2 of 5, which
is referred to in the “Use Code ID” function (see page 11).
Default is letter “I”.
•
Fix Length (by first 3 reads) fixes the length of acceptable
subsequent bar code reads from the first three bar codes read.
Useful as a data verification if all bar codes are of a consistent
length. Default is “No”.
•
Check Digit defines whether or not a check digit (to insure data
accuracy) is calculated, and if so, whether it should be sent or
not. Default is “Not Calculate”.
•
Suppress Digit suppresses the output of the first or last bar
code digit. Default is “Not Suppressed”.
•
Minimum Length defines the minimum length the user will
accept for a valid bar code. Default is “10”.
•
Maximum Length defines the maximum length the user will
accept for a valid bar code. Default is “64”.
•

Unitech MS100 Specifications

General

Wavelength	660 nm
Sensor type	Photo diode
Tilt reading angle	45 - 90 °
Dimensions (WxDxH)	140 x 30 x 23 mm
Cable length	1.80 m
Standard interfaces	RS-232
Power consumption	800 mA
Power requirements	5V DC
Product color	Black, Blue
Housing material	Plastic
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	76.5 g
