Unitech MS100 User Manual

ENVIRONMENTAL
-4° to 158° F (-20° to 70° C)Storage:
Temperature: Operating: 32° to 131° F (0° to 55° C)
Humidity: 20% to 85% RH non-condensing
SPECIFICATIONS
MS100 Manual
48
PERFORMANCE
Resolution: 5 mils (.012mm) min.
Light Source: 660nm Red LED
Depth of field: 0.04” (0.1mm)
Scan rate: 2” (50mm) to 30” (750mm) per second
Print Contrast Ratio: 0.5 min.
Reading Angle: 0° to 45°
0.18mm @ PCR 0.5
Minimum Bar Width: 0.12mm @ PCR 0.9
DECODER
Configuration: Via Scanner Configuration Manager software
(downloadable from www.ute.com) or bar code
setup menus in manual
Data Editing: Almost unlimited
Interfaces:
PS/2, RS232, TTL, USB (see next page for pinouts)
Symbologies: Codabar, Code 11, Code 32, Code 39 (Standard
and Full ASCII), Code 93, Code 128, Delta Code,
EAN-8, EAN-13, Label Code IV and V, MSI Code,
Plessey Code, Standard 2 of 5, UPC-A, UPC-E
MECHANICAL / ELECTRICAL
TTL (Undecoded): 35mA
Weight: 4 oz. (113 grams)
Cord: 45” (114cm) coiled, unstretched
Power consumption: Decoded: 70mA
Voltage: 5 Volts DC
Dimensions: 5.4375” L x 1.25” W
(138mm L x 32mm W)

Unitech MS100 Specifications

General

Wavelength	660 nm
Sensor type	Photo diode
Tilt reading angle	45 - 90 °
Dimensions (WxDxH)	140 x 30 x 23 mm
Cable length	1.80 m
Standard interfaces	RS-232
Power consumption	800 mA
Power requirements	5V DC
Product color	Black, Blue
Housing material	Plastic
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	76.5 g
