Unitech MS100 User Manual

30 MS100 Manual
Keyboard Interface
Caps-Lock: (see page 7)
0 - Auto Trace (PC/AT)
1 - Lower Case 2 - Upper Case
Function Code: (see page 7)
0 - Off 1 - ON
Language (For PC/AT): (see page 8)
9 - Alt Key Mode
Enter Group 3 Group Default
B1
B2
B3
Exit
0
1
2
3
4
5
6
7
8
9
:
0 - Disable 1 - Enable
Use Number Keypad Digits: (see page 8)
B8
0 - U.S.
3 - Swedish
6 - Italian
1 - U.K.
4 - Spanish
7 - German
2 - Swiss
5 - Norwegian
8 - French
: - Danish

Unitech MS100 Specifications

General

Wavelength	660 nm
Sensor type	Photo diode
Tilt reading angle	45 - 90 °
Dimensions (WxDxH)	140 x 30 x 23 mm
Cable length	1.80 m
Standard interfaces	RS-232
Power consumption	800 mA
Power requirements	5V DC
Product color	Black, Blue
Housing material	Plastic
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Weight	76.5 g
