Unitech MS836 User Manual

Sensitivity: This parameter specifies the degree o f
a c u t e n e ss o f t h e s c a nn e r ’s r e s po n s e t o changes in
ambient illumination. The higher the sensitivity, the
lower requirement in illumination change to trigger
the scanner. You can select an appropriate degree
of sensitivity that fits the ambient environment.
High Sensitivity
WFF0305
WFF0310
WFF0330
M00031A
Medium Sensitivity
* Low Sensitivity
Custom Sensitivity
Sensitivity levels range from 0 to 255. The smaller
the number, the higher the sensitivity.

Unitech MS836 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	100 reads/s
Maximum scan area	220 x 250 mm
Maximum scan width	220 mm
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), Interleaved 2 of 5, MSI, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Power consumption	85 mA
Buzzer	Yes
Certification	CE, FCC
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP42
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	95 mm
Width	70 mm
Height	160 mm
Weight	150 g
