Unitech MS836 User Manual

Chapter 4 Symbologies
Introduction
Every symbology (barcode type) has its own
unique attributes.This chapterprovides
programming barcodes for configuring the
scanner so that it can identify various barcode
symbologies. It is recommended to disable
those that are rarely used to increase the
efficiency of the scanner.
Global Settings
WFFD981
WFFD982
WFFD990
W016101
W016100
Enable All Symbologies
Disable All Symbologies
Restore the Factory Defaults
of Code 128
*Enable Code 128
Disable Code 128

Unitech MS836 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	100 reads/s
Maximum scan area	220 x 250 mm
Maximum scan width	220 mm
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), Interleaved 2 of 5, MSI, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Power consumption	85 mA
Buzzer	Yes
Certification	CE, FCC
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP42
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	95 mm
Width	70 mm
Height	160 mm
Weight	150 g
