Unitech MS836 User Manual

Enable 2-Digit Add-On Code/ Enable 5-Digit Add-
On Code: The scanner decodes a mix of EAN-13
barcodes with and without 2-digit/5-digit add-on
codes.
Disable 2-Digit Add-On Code/ Disable 5-Digit Add-
On Code: The scanner decodes EAN-13 and
ignores the add-on code when presented with an
EAN-13 plus add-on barcode. It can also decode
EAN-13 barcodes without add-on codes.
Transmit System Character
The first character of UPC-E barcode is the system
character
W306A10
Do Not Transmit System
Character
W306A20
*Transmit System Character

Unitech MS836 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	100 reads/s
Maximum scan area	220 x 250 mm
Maximum scan width	220 mm
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), Interleaved 2 of 5, MSI, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Power consumption	85 mA
Buzzer	Yes
Certification	CE, FCC
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP42
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	95 mm
Width	70 mm
Height	160 mm
Weight	150 g
