General| Type | Handheld bar code reader |
|---|---|
| Wavelength | 650 nm |
| Sensor type | Laser |
| Scanner type | 1D |
| Read rate (max) | 104 reads/s |
| Linear (1D) barcodes supported | Codabar, Code 128A, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI |
| 2D (matrix & stacked) barcodes supported | Not supported |
| Bluetooth version | 2.1+EDR |
| Standard interfaces | Bluetooth, USB |
| Connectivity technology | Wired & Wireless |
| Certification | CE, FCC, BSMI, VCCI |
| Keys quantity | 3 keys |
| Product color | White |
| Internal memory | 16 MB |
| Built-in display | Yes |
| Housing material | - |
| Display resolution | 128 x 64 pixels |
| Display technology | OLED |
| International Protection (IP) code | IP42 |
| Battery capacity | 680 mAh |
| Power source type | Battery |
| Storage temperature (T-T) | -30 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Harmonized System (HS) code | 84716070 |
Weight and Dimensions| Depth | 95.9 mm |
|---|---|
| Width | 36.9 mm |
| Height | 21.1 mm |
| Weight | 63 g |
Information about the manual's purpose, content, and usage guidelines.
Statements regarding compliance with various regulatory standards and rules.
Declaration of conformity with EU directives for radio, EMC, and low voltage.
Compliance with EU requirements for limiting public exposure to electromagnetic fields.
Conformance to European Union regulations on hazardous substances in electronics.
Details on laser safety, certifications, and warning labels for laser components.
Information about LED indicators and their safety for human eyes.
Important notices and recommendations for battery care, usage, and disposal.
Guidelines for storing batteries and product operation temperature conditions.
Recommendations for operating and storing the product within specified temperature limits.
Important notices regarding the use and care of the power adapter.
Warning about listening at high volume levels for extended periods to prevent hearing damage.
Contact information and website links for global support and regional service representatives.
Information on the limited warranty, conditions for voiding the warranty, and exclusions.
Lists the standard package contents and optional accessories included with the MS916 gift box.
Provides a detailed breakdown of the scanner's components and their functions.
Lists the technical specifications of the scanner, including system, optical, and electrical details.
Instructions on how to turn on/off the scanner and basic operation.
Instructions on how to charge the scanner's battery using a USB connection.
Explains the meaning of LED indicators and beeper sounds for different statuses.
Outlines the structure of the scanner's menu system for configuration.
Step-by-step guide to establishing a Bluetooth connection in HID mode.
Instructions for establishing a Bluetooth connection using the SPP profile, including driver installation.
Guide to establishing a Bluetooth SPP connection with the scanner acting as a slave device.
Steps to establish a connection using USB SPP mode, including driver installation.
Configuration options for enabling or disabling UPC-A, UPC-E, UPC-E1, and EAN-8 symbologies.
Options to enable or disable Code 128 and GS1-128 barcode symbologies.
Options for enabling/disabling Code 39, Trioptic Code 39, and Code 32 conversion.
Options to enable or disable Code 11 and configure its length settings.
Options to enable/disable Interleaved 2 of 5 and configure its length settings.
Options to transmit code ID characters for identified barcode types.
Setting decode security levels for linear barcode types to improve scan accuracy.
Configuration options for factory default settings and displaying firmware versions.
Setting the time frame for the scanner's automatic power off feature.
Configuring the time frame for the scanner's power saving mode.
Instructions to enter pairing mode and remove paired devices via scanning barcodes.
Configuring data transmission modes like Auto, Wedge, and Batch.
Settings for Bluetooth HID keyboard block delay, inter-character delay, and case.
Configuring beep volume, vibration function, and various indicator settings.
Options for scanner trigger modes: Trigger, Pulse, Continuous, and Flash.
Setting the maximum time for decode processing during a scan attempt.
Setting the duration for the scanner's aim pattern visibility.
Setting minimum time before decoding an identical symbol to avoid double scans.
Enabling transmission of "NR" message when a symbol cannot be decoded.
Setting prefix and/or suffix values and data terminators for scanned data.
Configuring 1:1/1:N checking functions and lookup tables for data validation.
Setting date/time stamps, hotkeys, and data view/erase functions.
Steps to detect Bluetooth signal strength.
Setting up label format and scanning barcodes for Bluetooth pairing.
Explanation of AIM Code Identifiers, including flag and modifier characters.
