Unitech MS916 User Manual

- 15 -
Chapter 2 - Installation
2.1 BT HID
BT HID*
Establishing BT connection in BT HID mode.
1. Use MS916 to scan BT HID barcode.
2. Press Down key and Scan button at the same time to enter BT pairing
mode.
3. Double-click Bluetooth
®
Device icon in the toolbar on your PC. Select Add
New Devices. When you see a device list windows, choose MS916-XXXX
and then press Next. PC now is establishing BT connection.
4. MS916 will beep when your PC successfully establish a BT connection with
MS916.

Unitech MS916 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	104 reads/s
Linear (1D) barcodes supported	Codabar, Code 128A, Code 32, Code 39, Code 93, EAN-13, EAN-8, MSI
2D (matrix & stacked) barcodes supported	Not supported
Bluetooth version	2.1+EDR
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Keys quantity	3 keys
Product color	White
Internal memory	16 MB
Built-in display	Yes
Housing material	-
Display resolution	128 x 64 pixels
Display technology	OLED
International Protection (IP) code	IP42
Battery capacity	680 mAh
Power source type	Battery
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	95.9 mm
Width	36.9 mm
Height	21.1 mm
Weight	63 g
