Start-up 7
0020291573_00 Heat pump control interface module Installation instructions 19
7.3.1 Ending the installation assistant
▶ Once you have run through the installation assistant suc-
cessfully, confirm by pressing
.
◁ The installation assistant will close and will not launch
again when the product is next switched on.
7.4 Menu functions without the optional system
control
If no system control is installed and this has been confirmed
in the installation assistant, the following additional functions
are displayed in the product's control panel:
– End user level
– Room temperature setpoint
– Screed drying activ.
– Target cylinder temp.
– Domestic hot water cylinder temp.
– Manual cooling activation
– Installer level
– Heat curve
– Summer sw.-off temp.
– Heating biv. point
– DHW bivalence point
– Heating alt. point
– Max. flow temperature
– Min. flow temperature
– Heating mode activ.
– DHW activation
– Cyl. charg. hysteresis
– Limp home mode Immersion heater: Heating/DHW
– Cooling target flow
– Screed drying day
If the system control has been retroactively removed or a de-
fect is present, you must reset the product to the factory set-
ting and select the system control in the installation assist-
ant in order to obtain the additional functions in the product's
control panel.
7.5 Calling up the installer level
1. Press
and at the same time.
2. Navigate to Menu → Installer level and confirm by
pressing
(OK).
3. Set the value 17 and confirm by pressing
.
7.6 Checking the configuration
You can recheck and set the most important system para-
meters. Call up Configuration to configure the menu item.
Menu → Installer level → Configuration.
7.7 Calling up statistics
Menu → Installer level → Test menu → Statistics
You can use this function to call up the statistics for the heat
pump.
7.8 Displaying the filling pressure in the building
circuit
The product has a pressure sensor in the heating circuit and
a digital pressure display.
▶ Select Menu Live Monitor to display the filling pressure
in the building circuit.
7.9 Checking the heating mode
▶ Start check programme P.04.
7.10 Checking the domestic hot water generation
▶ Check whether the cylinder is purged and the domestic
hot water temperature is reached.
7.11 Floor drying
Caution.
Risk of damage to the product caused by
impermissible purging
Without purging the heating circuit, the sys-
tem may become damaged.
▶ If the screed drying is activated without a
system control, purge the system manu-
ally. No automatic purging takes place.
– You can use this function to "dry heat" freshly laid screed
in accordance with the construction regulations, accord-
ing to a defined time and temperature schedule, without
the need for a system control to be connected.
If there is no electric back-up heater, screed drying is
only possible with this product if the return temperature is
above 10 °C. This corresponds approximately to an outdoor
temperature of +5 °C. At outdoor temperatures below
+5 °C, there is a risk of increased icing of the fin-type heat
exchanger in the outdoor unit.
When screed drying is activated, all the selected operating
modes are interrupted. The function controls the flow tem-
perature of the controlled heating circuit according to a pre-
set programme, regardless of the outdoor temperature.
The display shows the target flow temperature. You can
manually set the current day.
Days after starting the func-
tion
Target flow temperature for
this day [°C]
1 25
2 30
3 35
4 40
5 45
6–12 45
13 40
14 35
