1
Introduction
This manual describes setup and operating procedures for the EMR
3
Electronic Meter Register System. This
manual assumes that the Display Head, Interconnection Box, and printer are installed and connected.
System Options
There are three options available for the EMR
3
System:
• Time and Date
• Currency Mode
• Temperature Compensation
References to Time and Date, Currency/Pricing, and Temperature Compensation are found throughout this manual
in setup charts and in operating instructions. The EMR will not display any setup steps connected to an option (in
Setup or C&C Modes) if that option is not installed. When using this manual, please ignore any references to an
option if it is not installed.
System Setup
There are two distinct categories of EMR
3
setup; Setup Mode which can be accessed at any time by the
equipment operator, and C&C (Configuration and Calibration) Mode which is only to be entered in accordance
with Weights and Measures (W&M) requirements.
SETUP MODE
The Setup Mode can be accessed by the equipment operator to:
• Establish price, tax, and discount codes,
• Set the shutoff points for preset flow control relays 1 and 2.
• View/print delivery records,
• Select a designated printer type,
• Set system component addresses,
• Set time delays to blank out display,
• Enter shift times, tanker reloads, and odometer readings, and print out end-of-shift activity reports,
• Enter security codes which can be assigned to delivery functions to prevent unauthorized changes.
• Provide Passcode login procedure for access to assigned setup categories.
• Restore up to the last 50 transaction records from IB NVRAM storage to a replacement Display Head,
• Select month, day, year date formats,
• Enter system Time and Date, and
• View component version numbers.
C&C MODE
The C&C Mode setups must be performed before you make selections in the non-metrological controlled Setup
Mode - There is one exception: When initially powering up an EMR
3
System with two Display Heads, System
Address Setup (in Setup Mode) must be completed before entering C&C Mode (see page 24 to page 27).
