Vertiv | eSure™ Rectifier Module User Manual (UM1R483500e3) | Rev. H
• EMI/RFI Suppression:
a) Rectifiers operating in an approved rectifier mounting shelf conform to the requirements of FCC
rules Part 15, Class B for radiated and conducted emissions limits.
b) Rectifiers operating in an approved rectifier mounting shelf conform to the requirements of
European Norm, EN55022, Class B for Radiated and Conducted emissions limits.
Compliance Information:
• EMC: ETSI EN 300 386, FCC CFR 47 Part 15 class B, Telcordia GR-1089-CORE.
• EMI Load Range: 5% - 100%.
• Safety: IEC 60950, EN 60950.
• REACH, ROHS:
REACH SVHC
Communication
Name of
SVHC above
0.1% (w/w)
CAS
Number Component
Diboron
trioxide
1303-86-2
Resistors,
Chip Ceramic
Capacitors
Lead
monoxide
1317-36-8
Chip
Resistors
EU RoHS
Compliant, Lead Free Soldering
Standard Features
• Type of Power Conversion Circuit: High frequency.
• Constant Voltage Mode: For any initial output voltage setting from 42 to 58 volts, output voltage
remains constant regardless of load. This is the normal operating condition, in which loads are being
supplied and batteries are float charged. Rectifiers operate in the Constant Voltage Mode unless load
increases to the point where the product of load current and output voltage is approximately 3500 W.
• Constant Power Mode: As load increases above approximately 3500 W (non-adjustable), output current
continues to increase, but output voltage decreases as required to maintain constant output power.
Rectifiers operate in the Constant Power Mode unless load continues to increase to the point where the
current limit setting is reached.
• Constant Current Mode: If load increases to the current limit setting, output voltage decreases linearly
to maintain output current at the current limit setting.
• Input Protection:
a) AC Input Fuses F101, F102: AC 300 V, 30 A, fast acting, ceramic.
To Next Page
