Table 5:
Exchange of Information between Rectifier and Controller
Commands / signals that can be
received by the Rectifier Module
from the Controller.
Information gathered by the
Controller from the Rectifier Module.
• Turn On/Off
• Current Walk-in On/Off
• HVSD (High Voltage Shutdown)
Reset
• Current Limit Adjustment
• Voltage Regulation
• Input Voltage
• Output Voltage
• Output Current
• Current Limit Setting
• Temperature
• Over Voltage Setting
• On/Off Status
• Fault Alarms, such as:
HVSD
Fan Fail
• Protection Alarms, such as:
Input Voltage Protection
Inner DC Bus Voltage Protection
High Temperature Protection
• Thermal Derating
• AC Derating
• AC Fail
• Imbalance Output Current
• Address
• Code
• Date
• Software Version
•
Hardware Version
Mechanical Specifications
• Dimensions:
a) Millimeters: 42.0 (Height) X 84.5 (Width) X 330 (Depth)
b) Inches: 1.7 (Height) X 3.3 (Width) X 13.0 (Depth)
• Weight: 1.7 kg (3.7 lbs)
• Indicators:
a) Power (Green)
b) Protection (Yellow)
c) Alarm (Red)
