Vertiv™ NetSure™ 5100 Series -48 VDC Power System User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
39
5 Troubleshooting and Repair
5.1 Contact Information
Refer to Section 4154 (provided with your customer documentation) for support contact information.
5.2 Controller, Rectifiers, Solar Converters, Optional -48 VDC to +24 VDC
Converters, Optional -48 VDC to -58 VDC Converters and Optional
Inverters
For troubleshooting and repair instructions on these units, refer to the following documents.
• NCU Controller Instructions (UM1M830BNA)
• Rectifier Instructions (UM1R482000E3)
• Solar Converter Instructions (UM1S482000E3)
• -48 VDC to +24 VDC Converter Instructions (UM1C48241500)
• -48 VDC to -58 VDC Converter Instructions (UM1C48582000P3)
• Inverter Instructions (UM1I1201000)
5.3 Controller Configuration
If any controller configuration settings were changed, refer to the NCU Instructions (UM1M830BNA) and save a copy of the
configuration file. This file can be used to restore the controller settings, if required, at a later date.
NOTE! Provided on a USB drive furnished with the system is a controller configuration drawing (C-drawing) and the
controller configuration files loaded into the controller as shipped.
5.4 System Troubleshooting Information
This system is designed for ease in troubleshooting and repair. The various indicators as described in “Local Controls and Indicators”
on page 6 and in the controller, rectifier, solar converter, -48 VDC to +24 VDC converter, and -48 VDC to -58 VDC converter
instructions are designed to isolate failure to a specific element. Once the faulty element has been identified, refer to “Replacement
Information” on page 41 and “Replacement Procedures” on page 41.
Troubleshooting Alarm Conditions on the Controller
The controller displays alarm conditions as listed in the “Resolving Alarms” section of the controller’s User Manual. Programmable
external alarm relays are also available. Refer to the System Installation Instructions (IM582137100) and the configuration drawing
(C-drawing) supplied with your power system documentation for your alarm relay configurations.
The controller’s Active Alarm and Alarm History submenus allow the User to view alarm details. Refer to the NCU Instructions
(UM1M830BNA) to access these menus.
Checking the Controller’s Current Limit Point after Adding or Removing a Rectifier, -48 VDC to +24 VDC
Converter Module, or -48 VDC to -58 VDC Converter Module
If a rectifier, -48 VDC to +24 VDC converter module, or -48 VDC to -58 VDC converter module is added; the respective current limit
point in amps will automatically increase to maintain the same percentage. For example, if the current limit was set to 100% of
combined capacity and a module is added, the new current limit setpoint will be 100% of the combined capacity including the new
module.
