MGW Ace Encoder HEVC Encoding and Streaming Appliance
User Manual, Version 2.1 41
Target Section
Two targets are available from the same video channel. Select the Target 1 or Target 2 tab
accordingly, to specify and enable two different targets.
Enter the channel name. This name will also appear in Session
Announcement Protocol (SAP) messages.
Select the streaming protocol.
Enter the target IP address.
Select the network interface to stream from while using a multicast
target address.
In case, a unicast stream requires to be routed through a specific
Ethernet Port, refer to the Note below.
Enter the TTL value
Time-to-live (TTL) tells a network router whether or not the packet
has been in the network too long and should be discarded. Each time
an IP packet hits a router, TTL value is reduced by 1. If TTL remains
greater than 0, the router forwards the packet, otherwise it is
discarded.
Set a value high enough to ensure streaming packets are reaching
the decoder.
TTL value can be found by pinging the remote decoder.
The Value range is 1-255.
Enter the UDP packet size value.
Some transmission link accepts only smaller UDP packet size. Reduce
the UDP packet size if experiencing decoding problems.
Select the SAP check box to enable Session Announcement Protocol.
Select the Traffic Shaping check box to enable network smoothing.
Error Correction Settings
Available with Zixi
TM
and Pro-MPEG mode. See details below.
Available for RTMP mode (H.264). See details below.
