MGW Ace Encoder HEVC Encoding and Streaming Appliance
User Manual, Version 2.1 54
To set KLV Capture over Serial / RS232 Port:
In the KLV Input>RS-232 Serial tab screen set the following parameters:
Figure 4-13: The KLV Input screen
Serial Configuration
Parameter
Description
Baud Rate
Select the baud rate.
Data Bits
Select the data bits.
Parity
Select the parity.
Stop Bits
Select the stop bits.
Flow Control
Select the flow control.
KLV
Parameter
Description
KLV Input Data Format
Select the data format.
KLV Output Data Format
Select the data format.
