Vogt VT40 Service Manual

3-2 Vogt
®
VT Service Manual
Model Specifications
Vogt Ice Vertical Tube
Model Number Structure
VT
6
B
– P
F
26
AC
H
G
00
Condenser
“NC” – No Condenser
"AC" – Air Cooled
"WC" – Water Cooled
“SW” – Sea Water
“RC”
–
Remote Air
Basic Model
“VT” – Vertical Tube
Nominal Capacity
in 1000’s of lbs
“4” – 4000 lbs
“6” – 6000 lbs
“8” – 8000 lbs
“10” – 10000 lbs
Configuration
"P" – Package
"L" – Low-side
"H"
–
High
-
side
Compressor Size
“0” – No Compressor
“F” – 5 ½HP
“G” – 7HP, 3cyl, 2120 CFH
“H” – 7HP, 4cyl, 2380 CFH
“J” – 10HP
“K”
–
12.5HP
Revision Level
A letter assigned to indicate
major revisions within any one
family series.
Refrigerant
"F" - R22
"H" – R404A
Electrical Codes
"26" - 208/230-3-60
"46" - 460-3-60
"25" - 200-3-50
"45" - 400-3-50
“35” – 380-3-50
"21"
-
230
-
1
-
60
Product Variation Codes
( A number or letter designator assigned to specific variations within a family.)
“01” – CE Approved, no skins
"00 or Blank" – Standard Product
“NS” – No skins (on condensing unit)
“WS” – With skins (on condensing unit)
“RS” – Remote Start Switch
Skin (casing) Material
“G” – Galvannealed
“S” – Stainless Steel

Vogt VT40 Specifications

General

Brand	Vogt
Model	VT40
Category	Ice Maker
Language	English
