Vogt
®
VT Service Manual 4-5
Initial Startup
Removing Refrigerant:
To remove refrigerant from an overcharged system, refrigerant gas may be
removed from suction line ¼” access port (See Figure 4-7). For quicker removal, liquid refrigerant may be
reclaimed from the liquid line.
VT80/VT100 – access port on liquid line ball valve
VT60 – access port on receiver rota-lock valve
VT40 – access port in liquid line
FIGURE 4-7
Access Fitting for Removing Refrigerant
Note: Follow all EPA regulations and guidelines when handling refrigerant.
VT80 & VT100
Liquid line Ball Valve
with ¼” access port
Receiver Service Valve – rotalock
valve with ¼” access port
Liquid line Ball Valve
with ¼” access port
