Vogt VT40 Service Manual

8-18 Vogt
®
VT Service Manual
Service Operations
Replacement Parts List
Control Panel Components (Low-Side)
Part Number Req’d Description
12A2117G09 1 ELECTRONIC BIN THERMOSTAT
12A2117G0901 1 ELECTRONIC THERMOSTAT PROBE
12A7500E61 1 A/B SELECTOR SWITCH, 3 POSITION, SS, Ice-Clean-Off Selector Switch
12A7500E73 1 CONTACT BLOCK/MOUNTING LATCH, 2-NO, For Ice-Clean-Off Switch
12A7500E56 1 A/B PUSH BUTTON SWITCH (GREEN), PB1- Manual Harvest/Start Switch
12A7500E75 1 CONTACT BLOCK/MOUNTING LATCH, 1-NO, For Manual Harvest/Start Switch
12A7536M01 1 PROGRAMMABLE CONTROLLER (PLC)
12A7516E23 2 A/B CONTACTOR, 9-AMP, 3-POLE, 208/240V W/1-NO AUX, Cutter or Pump Contactor (CU or P)
12A7515E21 1 CONTROL CIRCUIT BREAKER, 3 AMP, 2-POLE, CB3/CB4
12A2117B03 1 PRESSURE SWITCH (PENN), HH-Harvest Hold Pressure Switch
12A2117B03CE PRESSURE SWITCH (DANFOSS) – CE APPROVED MACHINE
12A7520E33 1 INDICATOR LIGHT, 250V RED LENSE, 1LT-Fault Indicator Light
12A7520E36 INDICATOR LIGHT, 28VDC (SPECIAL)
12A7520E34 1 INDICATOR LIGHT, 250V AMBER LENSE, 2LT-Control Power Indicator Light
12A7537S07 1 CURRENT SENSING RELAY
Control Panel Components (Condensing Unit)
12A7516E29 1 A/B CONTACTOR, 43-AMP, 3-POLE, 208/240V W/1-NO AUX
C-Compressor Motor Contactor for VT40
12A7516E30 1 A/B CONTACTOR, 72AMP, 3-POLE, 208/240V COIL
C-Compressor Motor Contactor for VT60, VT80 & VT100
12A7518E30 1 A/B AUX. CONTACT, 3A, 1 NO/1 NC, (SIDE MOUNT)
Auxiliary Contact for Compressor Contactor, VT60, VT80 & VT100
12A7515E18 1 PUMP/CUTTER MOTOR CIRCUIT BREAKER, 2-POLE, 10 AMP
CB1-Control Circuit (Low-Side)
12A7515E19 1 CONDENSER FAN CIRCUIT BREAKER, 2-POLE, 15 AMP
CB2-Control Circuit (Condensing Unit)
12A2117A05 1 SENTRONIC OIL PRESSURE SAFETY CONTROL
12A2117B08 1 LOW PRESSURE CONTROL 20”-100#, 1/4”SAE, 36” CAP TUBE
12A2117H01 1 HIGH PRESSURE CONTROL, 50-450#, 1/4”SAE, 36” CAP TUBE
12A2117F05 1 CONDENSER FAN CONTROL SWITCH
12A2117G09 1 ELECTRONIC BIN THERMOSTAT – Remote condenser for VT80 & VT100 only
(Condenser Fan Cold Weather Thermostat)
12A7519E38CE 1
TRANSFORMER, 250VA, 400/200V PRI/120V SEC, 50/60HZ, FOR 120V WATER PUMP,
FOR CE APPROVED MACHINE
12A7537S06 1
POWER LINE FILTER, 10A, For CE Approve Machine
Chopper Assembly
19T2161C03 1 CHOPPER ASSEMBLY FOR VT60, VT80 & VT100 (B-SERIES)
19T2161C04 1 CHOPPER ASSEMBLY FOR VT40 (B-SERIES)
12A2020M19 1 BEARING, NYLON/STAINLESS STEEL BALL BEARING 1” BORE
12A4030R14 1 GEAR REDUCER, GROVE 5:1 RATIO
12A2900M0511
1
CHOPPER MOTOR, 1/2 HP, 3600 RPM, 115/230V-1PHASE
12A2900M0511CE CHOPPER MOTOR, 1/2HP, 3600 RPM, 220V, 50HZ–1PHASE – For CE Approve Machine
Circulating Water
12A4200H0401 1 FLOAT VALVE, ½” ROBERTS #RM214
12A4020H03 1 PUMP, HARTELL, 1/12HP, 208-230V, 50/60HZ
Replaces Beckett, Pump #12A4020B01
12A4020H03CE PUMP, ANJON, 1/5HP (144W), 115V, 50/60HZ – For CE Approved Machine
12A4181T04 6 TUBING, TYGON B-44-3, 1-1/4" OD x 1" ID
Circulating Water Tubing (Priced per Ft.)
12A2185D01 1 WATER DISTRIBUTOR FOR VT40
12A2185D02 1 WATER DISTRIBUTOR FOR VT60, VT80 & VT100
12A2150VT01 1 WATER PUMP COVER FOR VT (B-SERIES)
12A2150VT02 1 WATER FLOAT VALVE COVER FOR VT (B-SERIES)
12A2145VT02 1 ICE CHUTE COVER FOR VT60, VT80 & VT100 (B-SERIES)
12A2145VT04 1 ICE CHUTE COVER FOR VT40 (B-SERIES)
