IV - Assembly overview - drive
shaft with triple roller joint
AAR2600i ⇒ page 121
V - Assembly overview - drive
shaft with triple roller joint
AAR3300i ⇒ page 127
Distinguishing between drive shafts when installed
VL90 VL100 VL107 (bolt-
on)
VL 107 (push-
on)
AAR2600i AAR3300i
Diameter of
inner joint in
mm
90 100 107 - - -
Cover be‐
tween inner
joint and drive
flange
- - X - - -
With bearing
bracket on
right side
- - X - - X
Inner joint fit‐
ted in gearbox
- - - - X -
Inner joint
pushed onto
stub shaft
- - - x - -
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
7. Repairing drive shaft - overview of drive shafts 95
