P
r
o
t
e
c
t
e
d
b
y
c
o
p
y
r
i
g
h
t
.
C
o
p
y
i
n
g
f
o
r
p
r
i
v
a
t
e
o
r
c
o
m
m
e
r
c
i
a
l
p
u
r
p
o
s
e
s
,
i
n
p
a
r
t
o
r
i
n
w
h
o
l
e
,
i
s
n
o
t
p
e
r
m
i
t
t
e
d
u
n
l
e
s
s
a
u
t
h
o
r
i
s
e
d
b
y
V
o
l
k
s
w
a
g
e
n
A
G
.
V
o
l
k
s
w
a
g
e
n
A
G
d
o
e
s
n
o
t
g
u
a
r
a
n
t
e
e
o
r
a
c
c
e
p
t
a
n
y
l
i
a
b
i
l
i
t
y
w
i
t
h
r
e
s
p
e
c
t
t
o
t
h
e
c
o
r
r
e
c
t
n
e
s
s
o
f
i
n
f
o
r
m
a
t
i
o
n
i
n
t
h
i
s
d
o
c
u
m
e
n
t
.
C
o
p
y
r
i
g
h
t
b
y
V
o
l
k
s
w
a
g
e
n
A
G
.
8 - Front left vehicle level sender -G78-
❑ Removing and installing ⇒ page 15
❑ Can be tested in guided fault finding using ⇒ Vehicle diagnosis, testing and information system VAS 5051
9 - Bolt
❑ 9 Nm
10 - Suspension link
❑ Different versions of suspension links are possible (cast steel, aluminium).
❑ Allocation ⇒ Electronic parts catalogue “ETKA”
Note
❑ If damaged, also renew swivel joint.
❑ Removing and installing ⇒ page 36
❑ Renew bush ⇒ page 47
11 - Suspension link
❑ Different versions of suspension links are possible (welded steel sheet, single-shell steel sheet).
❑ Allocation ⇒ Electronic parts catalogue “ETKA”
Note
❑ If damaged, also renew swivel joint.
❑ Removing and installing ⇒ page 36
❑ Renew bush ⇒ page 47
12 - Nut
❑ M12 x 1.5
❑ 60 Nm
❑ Self-locking
❑ Always renew after removing
13 - Swivel joint
❑ Checking ⇒ page 33
❑ Removing and installing ⇒ page 34
❑ Renew together with suspension link if suspension link is damaged
14 - Nut
❑ For cast steel suspension link: 60 Nm
❑ For sheet steel and forged aluminium suspension link: 100 Nm
❑ Self-locking
❑ Always renew after removing
15 - Nut
❑ 9 Nm
16 - Bolt
❑ M12 x 1.5 x 100
❑ 70 Nm + 90° further
❑ Always renew after removing
17 - Bolt
❑ 20 Nm + 90° further
❑ Always renew after removing
18 - Bolt
❑ M12 x 1.5 x 75
❑ 70 Nm + 90° further
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
3. Subframe, anti-roll bar, suspension link 11
