– Remove clip -1-.
Note
Do not open brake line.
– Now strap vehicle to the lifting platform arms on both sides of
the vehicle using tensioning straps -T10038- .
WARNING
If the vehicle is not strapped down there is a great danger that
the vehicle will slip off the lifting platform!
– Position engine and gearbox jack -V.A.G 1383 A- with univer‐
sal gearbox support -V.A.G 1359/2- beneath subframe and
secure with strap.
– Unscrew one hexagon bolt -1- or -2- on both sides.
Note
Only the left vehicle side is shown to improve clarity.
To secure the subframe in place, ensure that at positions -1- and
-2- the locating pins -T10096- are screwed in one after the other
on both sides of vehicle.
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
206 Rep. Gr.42 - Rear suspension
