❑ 130 Nm + 90° further
❑ Renew each time after removing
❑ Always tighten threaded connections in unladen position ⇒ page 187
26 - Track rod
❑ Various versions
♦ Forwards closed (left and right track rods differ)
♦ Downwards open (left and right track rods identical)
❑ It is permitted to install mixed types.
❑ Allocation ⇒ Electronic parts catalogue “ETKA”
❑ Removing and installing ⇒ page 231
27 - Bolt
❑ M12 x 1.5 x 125
❑ 90 Nm + 90° further
❑ Renew each time after removing
28 - Bolt
❑ M12 x 1.5 x 95
❑ Renew each time after removing
❑ Always tighten threaded connections in unladen position ⇒ page 187
29 - Nut
❑ 90 Nm + 90° further
❑ Self-locking
❑ Renew each time after removing
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
12. Assembly overview - control arm, track rod (four-wheel drive, subframe made from steel and wheel bearing housing made from
aluminium) 225
