Note
Hang brake caliper from body.
– Remove cross-head screw for brake disc and remove brake
disc.
– Remove backplate.
– Remove bolt -arrow- for lower transverse link -1-.
Pressing out bonded rubber bush
– Attach tools as shown in figure.
1 - -3346/3-
2 - -3301-
3 - -3301/3-
4 - -41-501-
5 - -3350/1-
6 - -3346/2-
– Pull out bonded rubber bush by tightening spindle.
Pulling in bonded rubber bush
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
13. Assembly overview - wheel bearing housing, trailing link (four-wheel drive, subframe made from aluminium and wheel bearing housing
made from cast steel) 241
