– Set up tools as shown in figure.
1 - Tube -T10230/3-
2 - Thrust piece -T10230/10-
3 - Removal tool -3372-
4 - Thrust plate -VW 401-
5 - Thrust plate -VW 402-
– Press out bonded rubber bush.
Pressing in bonded rubber bush
– Place trailing arm on a flat surface.
– Mark a vertical line on trailing arm bush.
Dimension -A- = 114 mm
There are two different types of bonded rubber bushes. On both
types, the marked line must be between the projections -1- after
being pressed in.
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
13. Assembly overview - wheel bearing housing, trailing link (four-wheel drive, subframe made from aluminium and wheel bearing housing
made from cast steel) 249
