♦ Spring retainer -V.A.G 1752/4-
♦ Adapter -V.A.G 1752/9- , not illustrated
Removing
– Remove wheel.
– Insert spring compressor -3-.
WARNING
Make sure coil spring is properly seated in spring retainer -
V.A.G 1752/4- (risk of accident).
– Use a spanner or a reversible ratchet handle to compress
spring compressor.
– Compress coil spring until it can be removed.
– Remove spring.
1 - Adapter -V.A.G 1752/9-
2 - Spring retainer -V.A.G 1752/4-
3 - Spring compressor -V.A.G 1752/1-
Installing
Carry out installation in the reverse sequence, noting the follow‐
ing:
End of spring -arrow- must lie against stop on bottom spring seat.
– Install spring together with spring seat.
– The bottom spring seat has a pin.
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
258 Rep. Gr.42 - Rear suspension
