– Bolt bonded rubber bushes together using original bolt, mak‐
ing sure that both notches -arrows- line up precisely.
– Insert assembled bonded rubber bushes with bolt head down‐
wards into tube -T10214/2- .
1 - Thrust piece -T10214/3-
2 - Bonded rubber bush
3 - Tube -T10214/2-
4 - Tube -T10214/1-
5 - Thrust plate -VW 401-
6 - Thrust plate -VW 402-
– Press in bonded rubber bushes -1- until dimension -a- is ob‐
tained.
Dimension -a- = 2 - 3 mm.
– Align tube -T10214/2- with pressed-in bonded rubber bushes
on subframe. Corners of inner core should be parallel to edge
of assembly tool -T10244- .
The distance -a- must be identical on the right and left to ensure
parallel installation.
– Position subframe against smaller internal diameter of tube
-T10244/3-.
Golf 2004 ➤ , Golf Plus 2005 ➤
Running gear, axles, steering - Edition 08.2009
32 Rep. Gr.40 - Front suspension
