and correct routing and securing of
lines
WARNING
High voltage in the hybrid vehicle's high-voltage system! Risk
of electric shock! Before commencing any work, inspect high
voltage components in working area. Observe safety notes
⇒ Electric drive; Rep. gr. 00; Safety notes.
♦ All work on vehicles with high-voltage system must only
be carried out by persons who are at least qualified as
“electrically instructed person (EIP)”.
♦ In the event of conspicuous findings or uncertainties, con‐
tact your responsible high-voltage technician or specialist
electrician!
Carry out visual check
During visual check in motor compartment area, note power
and control electronics for electric drive, high-voltage cables for
battery and air conditioning compressor, high-voltage cable for
electric drive as well as high-voltage charging socket in tank
cap.
During visual check in area of underbody, note high-voltage
battery as well as high-voltage cables for battery.
Pay attention to the following during inspection:
♦ The high-voltage components must not reveal any external
damage.
♦ Insulation of high-voltage cables must not be defective or
damaged.
♦ Pay attention to unusual deformations of high-voltage ca‐
bles.
Note
Defects which are found must be immediately reported to the
responsible high-voltage technician.
4.20 Infotainment system: installing Digital
Manual
Checking and adjusting – prerequisites
• Transportation mode is deactivated.
Procedure
– Switch on infotainment system.
– Select Setup menu.
– Activate online mode.
– Call up notifications.
The following notification should be displayed:
““Digital Manual installation – installing content. Please do not
switch off ignition.””
If yes:
♦ Do not close the notification.
ID.4 2021 ➤
Maintenance - Edition 12.2020
42 4. Descriptions of work
