14.1 Removing
Note
When separating laser welded seams, ensure that the panels ly‐
ing behind are not damaged.
– Release original joint.
– Remove remaining material.
14.2 Installing
14.2.1 Preparing new part
Replacement part
♦ Seat cross member
– Drill 7 mm ∅ holes for SG plug weld seam.
14.2.2 Welding in
– Fit new part and secure.
– Check fitting to adjacent components.
– Weld in seat cross member, SG plug weld seam.
– Install seat outer cross member mounting
⇒ “12.2 Installing”, page 164 .
Jetta 2005 ➤
Body Repairs - Edition 04.2009
14. Renewing seat cross member 169
