7.2 Installing
7.2.1 Preparing new part
Replacement part
♦ C-pillar reinforcement
– Transfer parting cut to the new part and cut (when doing this
take 10 mm additional material for overlap into consideration
-shaded area-).
– Step -shaded area- on new part.
7.2.2 Welding in
– Fit new part and secure.
– Weld parting cut, SG continuous weld seam (staggered).
– Weld original joint, RP spot weld seam.
– Install side panel ⇒ “6.2 Installing”, page 205 .
Jetta 2005 ➤
Body Repairs - Edition 04.2009
212 Rep. Gr.53 - Body - rear
